Product

A state-of-the-art handheld narcotics detection device utilizing Raman spectroscopy technology, developed in collaboration with the U.S. Department of Defense. Featuring significant technological advancements over previous handheld Raman spectrometers, the device delivers faster results, analyzes more complex mixtures, provides enhanced safety features, and offers expanded reporting capabilities. It is a modern solution for law enforcement agencies seeking the latest drug identification technology.

Built to create powerful, secure networks anywhere, the MPU5 unites all your critical data sources in real time – giving you access to the most advanced, most scalable Mobile Ad Hoc Network (MANET).

Naval Hull Mounted Sonar System (NHMSS) for MCMV (Mine Counter Measure Vehicle) is a Sonar system that its dome is mounted on the bottom of the ship’s hull to search, detect, classify and identify the targets such as mines laid above or on the seafloor. SEAView-1030 is designed for sea mine hunting then display its CONTINUOUS TARGET SIGNALS without getting disrupted from the interference of other backscatters such as ambient noises, false signals... The above mentioned technology is TGT (Tracking Guide Technology), one of the state-of-the-art technology for the MCM (Mine Counter Measure) operations. It is very convenient and accurate to classify real or false target from any of returning signals.

Specifications:

- Transmit power: more than 5kW

- Detection range of anchored mines (-15dB): 1000m

- Transmit frequency:

HF : 300kHz

LF : 100kHz

- Transmit wave: CW & Chirp(band : ±25kHz)

- Searching arc up to 120 degrees

Receive beam width:

HF: ≤1/3°

LF: ≤1°

Resolution: ≤ 3cm

- Pulse length:

HF : 20~400us

LF : 40~1,000us

Chirp (HF/LF) : 250~2,000us

- Size: 1,830(H) x 1,355(W) x 1,020(D) mm

- Weight: 580 kg

- Military mine-scanning software:

TGT(Tracking Guide Technology)

Equipment Condition Check Function

Electronic Chart Mapping Function

Target Searching Function

3D Target Identification Function

SAS technology applied (when operating speed scan)

The Mine Identification Disposal System (MIDS) with a maximum diving depth of up to 300m and an operating radius of up to 1000m used to search, detect and identify mines by image (camera or sonar).

After identifying the mine, The Mine Identification Disposal System (MIDS) is capable of carrying a specialized detonator to attach to the mine and safely detonate it.

1. MIDS configuration:

MIDS includes:

• 1 set: 7 Thruster vectored vehicle with Controller, Forward tilting HD x16 Zoom Camera, Dual LED Lights.

1 set: Dual-frequency sonar offering 120 meter range capability at 750kHz and 40 meter range at 1.2MHz.

• 1 Navigation Package: Autopilot System Defender (DVL, GPS & Integration)
• 1 set Acoustic Positioning System - 300m Depth Rating, Range Rating

1km.

- 1 set Rotating Manipulator Kit: Full 360º head rotation and five interchangeable jaws

- 1 Detonation controller with 20 specialized detonators

2. Specifications:

• Depth Rating: 300m (1,000ft)

- Size (l x w x h): 75.16 x 39.37 x 26.67 cm

• Weight: 17.2 kg

Camera:

+ HD with Ethernet interface (IP)

+ Video: 1920 x 1080, 25 FPS

+ Features: White Balance Control, 16x Digital Zoom (64 steps), 13 Megapixel Still Image Capture

+ Sensitivity: Less than 1 lux (standard)

+ View Angle: 160 degrees Tilt (180-degree FoV)

- Propulsion:

+ Brushless thruster with integrated controller

+ 4 Vectored Horizontal Thrusters: Forward 26.7 kg

Reverse 15 kg

Lateral 8.6 kg

+ 3 Vertical Thrusters: Up 23.1 kg

Down 12.9 kg

• Power:

+ 400 VDC power module

+ 1500W @ 48VDC

+ Full monitoring of input voltage, output current, temperature

• Communications:

+ 5 x 100Mbps Ethernet ports

+ 5 x RS-485 ports

Lighting:

+ LED

2 independent light arrays each at 38 Watts max

+ 60-degree spot beam

+ 110-degree flood beam

LOCUST is a multi-mission laser weapon system designed to function both as a Counter-Unmanned Aircraft System (C-UAS) and a Short-Range Air Defense (SHORAD) system. It is a compact, highly mobile weapon platform.

Model: TITAN
Manufacturer: BlueHalo
Country of Origin: United States

Model: MEDUSA-CG
Manufacturer: Passive Force
Country of Origin: Finland

1. Function

The long-range anti-approach laser device emits a high-power green laser beam intended to produce glare and deter approach at long range without causing injury to the target. It is designed for maritime security forces, anti-smuggling operations, anti-drug trafficking missions, riot control, and the protection of critical facilities and restricted areas.

2. Scope of Supply

• Long-range anti-approach laser device: 01 unit
• USB flash drive containing technical specifications and electronic user manual: 01 unit
• Rechargeable battery: 02 units
• Shoulder strap: 01 unit
• Battery charger: 01 unit
• Vehicle battery charger (car charger): 01 unit
• Accessory bag: 01 unit
• Carrying case: 01 unit

3. Technical Specifications

3.1. Laser Module

• Laser output power: 5000 mW
• Wavelength: 520 nm
• Beam divergence: 10 mrad
• Flashing frequency: 10 Hz

3.2. Power Supply

• Rechargeable lithium batteries: supplied with two removable rechargeable batteries, each rated at 12 V – 4 Ah, with a total capacity of 8 Ah
• Protection: overvoltage and overcurrent protection, designed to comply with MIL-STD-1275D
• Battery endurance:
  • More than 30 minutes (continuous laser emission mode)
  • More than 50 minutes (flashing laser emission mode)

3.3. Connections and Controls

• Charging connector: MIL-C-26482 standard
• Battery charger: 100–240 V, 50 Hz, maximum 1 A
• Laser firing control: trigger-operated

3.4. Mechanical Characteristics

• Total weight (including batteries): 4.7 kg
• Dimensions (with top-mounted Picatinny rail):
  • 740 (L) × 200 (H) × 65 (W) mm

3.5. Packaging and Environmental Conditions

• Dust and water protection: IP66 rated
• Operating temperature: -20°C to +60°C
• Operating humidity: 100% relative humidity, non-condensing
• Material: aluminum
• Cooling system: active cooling, fan airflow rate of 622 liters/minute

3.6. Laser Safety

• Laser safety classification: compliant with IEC 60825-1

3.7. Effective Operating Range (Under Standard Conditions)

• Effective glare range (daytime): 252 m
• Effective glare range (nighttime): 798 m
• Warning range (daytime): 505 m
• Warning range (nighttime): 1,596 m
• Minimum eye-safe distance: 50 m
• Skin-safe distance: 1 m

The short-range anti-approach laser device emits a medium-power green laser beam designed to cause temporary glare and deter approach at close range without causing injury to the target. It is intended for use by maritime security forces, anti-smuggling operations, anti-drug enforcement, riot control, and the protection of critical facilities.
